· UPS level redundant protection against backup load breakdown

· Internal EMS optimizes home energy supply automatically

· Bulit-in electric power service, FCAS, VPP, etc

Venus 5000 HVS Hybrid Inverter Tech Specs

Rated Output Power (kVA)：3.68 / 5 /4.6 (DE)

Rated Grid Voltage (V)：230V

Grid Voltage Range (V)：180 -270

Max PV Input Votage (V)：580

Max Efficiency：97.3%

Communications：RS485 / USB/Wifi /Ethernet

Dimension (w*h*d)：720 *406 *220 mm

Weight (kg)：19.5 / 25

Protection Degree：IP65

Venus 5000 HVS Bttery Inverter Tech Specs

Rated Output Power (kVA)：5 /4.6 (DE)

Rated Grid Voltage (V)：230V

Grid Voltage Range (V)：180 - 270

Communications：RS485 / USB / Wifi /Ethernet

Dimension (w*h*d)：720*406*220 mm

Weight (kg)：18

Protection Degree：IP65

Venus 5000 HVS Battery System Tech Specs

Rated Capacity (kWh)：5.3 - 15. 9 (1-3 units)

Cell Type：LFP(LiFe P04)

Rated Voltage (V)：102.4 - 307. 2

Communications：CAN2.0, RS485

Dimension (w*h*d)：740*565*220 / 740*900*220 / 740*1235*220 (mm)

Weight (kg)：66/ 116/ 166

Protection Degree：IP65
